IONICON PTR-TOF-MS - Trace VOC Analyzer - PTR-TOF 1000
IONICON PTR-TOF-MS - Trace VOC Analyzer
Sensitivity: > 200 cps/ppbv
Resolution: > 1500
LoD: < 10 pptv
Overview
Enter into the world of PTR-TOFMS with IONICON’s PTR-TOF 1000 and benefit from all the advantages only powerful time of flight based solutions offer:
- the entire mass range in split-seconds - no selection of masses - no waiting
- fast and sensitive for complex VOC mixtures and
- high mass resolution for better separation and identification.
More than a hundred PTR-TOF 1000 installations all over the planet are proof of its popularity and reliability. The PTR-TOF 1000 is the first choice for various international research campaigns but especially for 24/7 industrial monitoring or mobile air quality lab applications. It comes with a fully integrated IONICON data acquisition and data treatment software suite and can optionally be configured as automated VOC monitor with a customized substances identification library.
The PTR-TOF 1000 is our most affordable time PTR-TOF trace gas analyzer. Don't settle for anything less advanced, robust and reliable!
But wait, the PTR-TOF 1000 is just the beginning: expect up to 10x higher sensitivity with the PTR-TOF 1000 ultra.
Technical specifications
| Mass resolution | > 1500 m/Δm (FWHM) for m/z > 79 |
| Response time | < 100 ms |
| Sensitivity | > 200 cps/ppbv for m/z 181 |
| Detection limits | < 10 pptv for m/z 181 (averaged over 1 minute) |
| Linearity range | 10 pptv - 1 ppmv |
| Adjustable flow | 50 - 800 sccm |
Inlet system heating range | 40 - 180°C (2nd inlet system and other inlet options on request) |
| Reaction chamber heating range | 40 - 120°C |
| Weight | < 125 kg |
| Dimensions (w x h x d) | 60x91x80 cm (23.7 x 35.9 x 31.5 in.) |
| Power supply | 115/230 V, standby/typical operation: < 400/500-800 W |
| Interfaces | -Touchscreen display 8x DI/O, 2x AI, 2x AO |
